KWC ZOE

Trim set - lever mixer - 2 outlet (tub)

20.204.510.000

124016 - 20.204.510.000 - ZOE - ZOE Trim set - lever mixer - 2 outlet

KWC ZOE

Trim set - lever mixer - 2 outlet (tub)

20.204.510.000 124016 EAN/GTIN: 7612158489052

* Trim kit with function unit
* Outflow top and below
* Turning handle for diverter
* KWC cartridge M 35 H
- with ceramic discs
- flow rate and temperature continuously variable
* Scope of delivery:
- Function unit, lever, cap, sleeve, cover plate, holder for escutcheon, diverter
- Fastening of the cover plate without screws
* To be ordered separately:
- Unit for concealed installation KWC BLUEBOX®
½", without shut-off valve, 39.999.900.931
¾" (½"), with shut-off valve, 39.999.910.931
Trim set Trim set with safety device in accordance with DIN EN 1717

Product Specifications

Handling
Front lever
Color code
chromeline
Installation_type
Wall-mounted
Article type
Lever mixer
Concealed unit
Trim set with safety device in accordance with DIN EN 1717
material
Brass
Maximum height
150 mm
Width maximum
150 mm
Acoustic group
I
Energy Label (CH)
C
Flow rate
19 l/min (3 bar)

Downloads

Product images

Technical Documents

With our proven Technologies and functions

Accessories

KWC BLUEBOX

Alignment set

Z.537.593

KWC BLUEBOX

Excutcheon extension 15 mm

Z.537.594.000

KWC BLUEBOX

Extension set

Z.537.595

KWC BLUEBOX

Reverse adapter

Z.537.953

KWC

Cartridge M 35 H

Z.537.582
